Thermal Sensor - Type Uncooled VOx(vanadium oxide) - Resolution(pixel) 640*512 - Pixel Size(
m) 12*12 - NETD ?20mK?0.02?? - Frame rate(Hz) 50 - Human Detection Distance(m) 2600 - Optics - Objective Lens(mm) 50 - Optical Magnification(x) 2.5 - Digital Zoom(x) 2/4/6/8 - Field of View (Horizontal) 7.0
- Field of View (Vertical) 7.0
- Field of View (Diagonal) 9.9
- Eye Relief(mm) 100 - Diopter Adjustment(D) 5 3 - Display - Type IPS - Resolution(pixel) 800*800 - Reticle Style 6 - Reticle Color 4(Red/White/Yellow/Green) - Scene Mode City/Rain/Forest - Image Mode WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY - Photo / Video - Photo resolution(pixel) 1536*1536 - Photo Format .JPG - Video Resolution(pixel) 768*768 - Video Format .mp4 - Storage(GB) Micro SD card (Max. 128GB) - Image Engine Pard IREA - Main function - LRF Detection Range(m/yds) 1000/1200 - Ballistic Calculator Yes - PIP Yes - Gyroscope Yes - Recoil-activated Recording Yes - Loop Recording Yes - Hot Track Yes - E-compass Yes - Microphone Yes - Firmware Upgrade Yes - Connections - USB Tpye-C Yes - HDMI output Yes - WiFi Yes - Supported Apps PardVision2 - Power Supply - Battery Type Lithium Ion 21700*1 - Output Voltage(V) 3.7 - Operating Time(h) ?5 - External Power Supply Type-C - Environmental characteristic - Protective Class IP67 - Operating Temp(
C/
F) -30 +55 / -22 +131 - Recoil Resistance(J) 6000 - Material - Housing Aluminium Alloy - Objective Lens All-glass multi-coated lens - Measurement - Product Dimension(with LRF L * W * H mm) 50mm lens: 182*68*79? - N.W/pcs(with LRF&battery g) Ocelot 480-50mm lens: 647.5g
