Sensor - Type Uncooled VOx(vanadium oxide) - Resolution(pixel) 640x512 - Pixel Size(
m) 12x12 - NETD(mK) 20 mK 0.02 - Frame rate(Hz) 50 - Detection distance(m) 2600/3900 - Optics - Objective Lens(mm) 50/75 - Optical Magnification(x) 2.5/3.8 - Digital Zoom(x) 2/4/6/8 - Field of view (Horizontal) 7.0
/4.7
- Field of view (Vertical) 7.0
/4.7
- Field of view (Diagonal) 9.9
/6.6
- Eye Relief(mm) 100 - Diopter Adjustment(D) -5 +3 - Display - Type IPS - Resolution(pixel) 800*800 - Reticle Style 6 - Reticle Color Red/White/Yellow/Green - Scene Mode City/Rain/Forest - Image mode WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY - Photo / Video - Photo resolution(pixel) 1536*1536 - Photo Format .JPG - Video Resolution(pixel) 768*768 - Video Format .mp4 - Storage(GB) Micro SD card (Max. 128GB) - Image Engine Pard IREA - Main function - LRF detection range(m/yd) 1000/1200 - Ballastic caculator Yes - PIP Yes - Hot Track Yes - Gyroscope Yes - Recoil-activated recording Yes - Loop recording Yes - E-compass Yes - Microphone Yes - Firmware Upgrade Yes - Connections - USB Type-C Yes - HDMI Output Yes - WiFi Yes - Supported Apps PardVision2 - Power Supply - Battery Type Lithium Ion 18650*1 - Output Voltage(V) 3.7 - Operating time(hmax) ?6 - External power supply(V) USB Type-C - Environmental characteristic - Degree of protection IP67 - Operating Temp(
C/
F) -30 +55 / -22 +131 - Recoil Resistance(J) 6000 - Material - Housing Aluminum Alloy - Objective Lens All-glass multi-coated lens - Measurement - Product Dimension/with LRF(L * W * H mm) Pantera 640-50mm Lens 364*93*82 - N.W/pcs(with LRF&battery g) Pantera 640-50mm Lens 681.5
