Main - Sensor 384x288 @ 17 um (NETD <40 mK) - Objective lens F38 / 1.2 - Magnification x 2.5-10 (x4 zoom) - Field of view (HxV) degrees / m@100m 9.8-7.3 / 17.2-13 - Detection range m 1350 - Sensor - Type uncooled - Resolution pixels 384x288 - Pixel pitch um 17 - NETD mK <40 - Frame rate Hz 50 - Optics - Objective lens F38 / 1.2 - Magnification x 2.5-10 - Field of view (HxV) degrees / m @ 100 m 9.8-7.3 / 17.2-13 - Eye relief mm 50 - Display - Type AMOLED - Resolution pixels 1024x768 - Range Performance - Detection range m 1350 - Reticle - Click value H/V mm at 100 m 17 / 17 (on minimum magnification) - Click range H/V mm at 100 m 3400 / 3400 - Number of preloaded reticles 10 - Video Recorder - Video / photo resolution pixel 1024x768 - Video / photo format .mp4 / .jpg - Built-in memory GB 16 - Wi-Fi - Wireless Protocol Wi-Fi - Wireless Standard IEEE 802.11 b/g/n/ac (WPA) - Frequency GHz 2.4 / 5 - Environmental Characteristics - Degree of protection IP code (IEC60529) IPX7 - Operating temperature range
C -25-+50 - Connections and Compatibilities - Max. recoil power on rifled weapon (Eo) Joules 6000 - Shock resistance on the smooth-bore rifles caliber 12 - Compatible mounts Weaver U Mount Weaver USQD Mount Weaver LQD Mount - Supported Application Stream Vision 2 - Power Supply - Output voltage V 3.0-4.2 - Battery type APS 5T - Capacity mAh 4900 - Operating time on battery pack (at t=22
C) h * 9 - External power supply V 5 V 9 V (USB Type-C Power Delivery) - Weight & Size - Body material Magnesium alloy - Dimensions mm 330x57x67 - Weight kg 0.7 (without APS 5T battery)
Products specifications
SubCategory
|
OPTICS-NIGHT VISION, Night Vision |
Manufacturer
|
PULSAR/SELLMARK |
Stock Status
|
Out of Stock, In Stock |
Category
|
OPTICS |
